Restaurant Design, Permitting and Construction, Elizabeth, NJ

Design and conversion of an existing jewelry store into a pizza shop in the city of Elizabeth, NJ. Conducted permit procurement,  designed proposed floor plan, construction details of proposed alterations. Provided egress calculations and markups, electrical and plumbing diagram of proposed alteration for both water supply lines and drainage for permitting approval. Provided a full construction drawing set to secure approval from the city authorities.



 SERVICES PROVIDED-

  • Structural Design

  • BIM Modeling

  • MEP Design

  • Permit Procurement

  • Construction Drawing Set
